RhinoGuard® 75/50 Protective Bollard
Add an effective vehicle protection measure to your urban project with RhinoGuard® 75/50 Protective Bollards. The crash tested RhinoGuard® technology built into the bollard's core provides a high level of protection in locations where large vehicles capable of carrying out high energy attacks are able to reach high speeds.
Tested in accordance with the PAS 68 standard, the RhinoGuard® 75/50 Protective Bollard is able to withstand the impact of a fully laden 7.5 tonne two axle rigid N2 lorry travelling at 50mph. The Ø244mm central core can be dressed with a number of different sleeve options to enhance the aesthetic, including stainless steel, steel and Ferrocast. A slimline option is also available.
75/50 Static Slim This product is capable of withstanding a 7.5 tonne vehicle travelling at 50mph. The security classification is V/7500(N3)/80/90:12.5/21.8
75/50 Static This product is capable of withstanding a 7.5 tonne vehicle travelling at 50mph. The security classification is V/7500(N3)/80/90:5.4/0.0
- Effective against attacks at 50mph
- Choice of 3 sleeve options
- Slimline version available
- Successfully crash tested to the BSI PAS 68 standard
Technical Downloads (5)
- street furniture maintenance guide Download street furniture maintenance guide
- rhinoguard 75 50 protective slimline bollard steel Download rhinoguard 75 50 protective slimline bollard steel
Certifications, Accreditations & Credentials
Technical Documents
- street furniture maintenance guide Download street furniture maintenance guide
CAD Details
- rhinoguard 75 50 protective slimline bollard steel Download rhinoguard 75 50 protective slimline bollard steel
- rhinoguard 75 50 protective slimline bollard stainless steel Download rhinoguard 75 50 protective slimline bollard stainless steel
- rhinoguard 75 50 protective bollard steel Download rhinoguard 75 50 protective bollard steel
- rhinoguard 75 50 protective bollard stainless steel Download rhinoguard 75 50 protective bollard stainless steel
Product Details
Product Name | Sleeve Material | Sleeve Finish | Core Diameter (mm) | Sleeve Diameter (mm) | Height Above Ground (mm) | Fixing Method | Core Weight (kg) | Sleeve Weight (kg) | Reflective Tape Available | Length (mm) | Height (mm) | Weight (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
RhinoGuard® 75/50 Protective Bollard Steel | Mild Steel | Galvanised & Powder Coated | 244 | 273 | 1100 | Root Fixed | 303 | 41 | Yes | 1850 | 1100 | 344 |
RhinoGuard® 75/50 Protective Bollard Stainless Steel | Grade 316 Stainless Steel | Brushed | 244 | 254 | 1100 | Root Fixed | 303 | 17 | Yes | 1850 | 1100 | 320 |
RhinoGuard® 75/50 Slim Protective Bollard Steel | Mild Steel | Galvanised & Powder Coated | 194 | 204 | 1000 | Root Fixed | 260 | 28 | Yes | 1600 | 1000 | 288 |
RhinoGuard® 75/50 Slim Protective Bollard Stainless Steel | Grade 316 Stainless Steel | Brushed | 194 | 204 | 1000 | Root Fixed | 260 | 12 | Yes | 1600 | 1000 | 272 |
