Tactile Blister Concrete Block Paving
In modern, multi-function urban landscapes, crossing points are frequently driven over or parked on, meaning tactile flag paving at crossing points can become damaged.
These cleverly designed concrete block paving units are capable of withstanding vehicular overrun from the heaviest loads on the road. The correct nib placement is also maintained to provide tactile guidance for visually impaired pedestrians and ensure DDA compliance.
This keeps crossings safe and neat, and can significantly reduce maintenance costs.
The blisters have been positioned in such a way that the blocks can be laid in any pattern while still maintaining the correct formation to satisfy BS EN 1339: 2003.
The 2 colour options allow for visual identification at crossing points - red for use at controlled crossings, buff at uncontrolled crossings.
Download the EPD for Tactile Blister Block Paving here.
- Protects crossing points from vehicular overrun
- 2 colour options for effective visual demarcation
- Helps reduce maintenance costs
- Ensures DDA compliance
Price Range
- £
- £
- £
Maximum Loading Classification i✕This is the maximum loading for the product.
However this is subject to using the appropriate installation method, bond pattern and the sub-base design.
For tailored support with a pavement design, please contact us:
grouptechnicalservices@marshalls.co.uk
However this is subject to using the appropriate installation method, bond pattern and the sub-base design.
For tailored support with a pavement design, please contact us:
grouptechnicalservices@marshalls.co.uk
Category 5 - 0.05msa Pedestrian areas subjected to occasional overrun of commercial vehicles. Car parks receiving occasional commercial vehicular traffic.
NBSPlus Codes
Q24 10
Q24 110
Q24 112
Q24 113
Carbon Footprint
From 15 kg CO2 per m²
Technical Downloads (2)
- tactile blister cpb 200x133x60 datasheet Download tactile blister cpb 200x133x60 datasheet
- EPD Marshalls Pigmented Concrete Block Paving Download EPD Marshalls Pigmented Concrete Block Paving
Certifications, Accreditations & Credentials
Datasheets
- tactile blister cpb 200x133x60 datasheet Download tactile blister cpb 200x133x60 datasheet
Technical Documents
- EPD Marshalls Pigmented Concrete Block Paving Download EPD Marshalls Pigmented Concrete Block Paving
Product Details
Product Name | id | Length (mm) | Width (mm) | Thickness (mm) | Approx Unit Weight (kg) | Approx Pack Weight (kg) | Pack Size (m²) | Finish | Made to Stock / Made to Order | Carbon Footprint |
---|---|---|---|---|---|---|---|---|---|---|
Tactile Blister CBP 200 x 133 x 60 Buff | PV4010750 | 200 | 133 | 60 | 3.2 | 1084 | 7.66 | Standard Concrete | Made To Order | 15 kg CO2 m² |
Tactile Blister CBP 200 x 133 x 60 Red | PV4011500 | 200 | 133 | 60 | 3.2 | 1084 | 7.66 | Standard Concrete | Made To Stock | 15 kg CO2 m² |
Made to stock: Item is in stock and available for delivery.
Made to order: Item will be manufactured when the order has been placed, lead times vary dependent on product.
